Moderate task, requires some mechanical/electrical experience.
Time to Complete: 2 hrs
This guide is a list of steps you will want to go through to ensure your miter cuts are the correct size. This guide is created for Saber, Voyager XP and Saberjet machines.
Scan to watch on mobile device
It is important to ensure you have a good table top prior to doing these corrections. Replacing the rubber slats, slat holders, backer boards or milling your table down maybe neccessary.
Dialing the Blade A and C Axis
Z Offset
Blade touch off and enter the blade kerf
Calibrate the height sensor
Blade Offset Cut
TCP Calibration Square – Waterjet Machines Only
Run a test program to verify miter cut sizing is accurate.
If you are still having miter size issues after performing these steps, you may need to go back and do the advanced machine offsets. There are links listed below:
Prior to beginning installation, operation, or maintenance, you are advised to carefully read ALL instruction manuals and ALL safety materials and procedures provided with your equipment.
You are solely liable for the proper operation and maintenance of the equipment.
Park Industries® is not responsible for and expressly disclaims liability for any injuries (including death) or damage to the equipment or any other property as a result of improper operation or maintenance of the equipment, as well as failure to comply with the procedures set forth in the equipment’s instructional manual or any other safety materials and procedures. If you encounter any problems or difficulties, you are strongly encouraged to seek professional assistance.
Safety is our number one concern. Should you have any questions don’t hesitate to call our service team at 800-785-3391.
