Moderate task, requires some mechanical/electrical experience.
Time to Complete: 20 min
Learn how to set up, use, and make a program for the backsplash jig on a Park Industries CNC saw.
Part 1. This video shows how to setup and align the BackSplash Jig from Park Industries. This can be used on all of our CNC Saws and Sawjets.
Chapters: 0:00 Introduction 0:25 Clamping the Jig 2:04 Aligning to the Blade 14:57 Shifting a program in Y 16:32 Running the Program 18:16 Flipping the Part 19:31 Preventing a nicked corner 21:00 Outro
Part 2. This Video shows how to make a program on the Park Industries Backsplash Fixture. Use the information in this video with the “Using the Backsplash Fixture” • Using the Backsplash Fixture video.
Chapters: 0:00 Introduction 0:21 Creating the part 1:44 Select Tool 2:01 Apply Toolpath 2:20 Correcting the Cut Settings
